제품 세부 정보
원래 장소: 중국
브랜드 이름: Beyde
인증: CE
모델 번호: 500/1+6
지불 및 배송 조건
최소 주문 수량: 1 세트
포장 세부 사항: 안전 컨테이너 포장
배달 시간: 90 일
지불 조건: l/c, d/a, d/p, t/t
공급 능력: 200 세트/년
용법: |
가닥 |
색상: |
고객 요구 사항에 따라 |
이름: |
관모양 스트랜딩 기계 |
애플리케이션: |
강철, 알루미늄, 가닥 스틸 와이어 |
와이어 재료: |
철, 구리 |
중심 페이-오프 실패: |
PN400-PN630 |
테이크-업 보빈 사이즈: |
PND800-PND1600 |
최대 벌거벗은 와이어 직경: |
4mm |
보증: |
12 개월 |
용법: |
가닥 |
색상: |
고객 요구 사항에 따라 |
이름: |
관모양 스트랜딩 기계 |
애플리케이션: |
강철, 알루미늄, 가닥 스틸 와이어 |
와이어 재료: |
철, 구리 |
중심 페이-오프 실패: |
PN400-PN630 |
테이크-업 보빈 사이즈: |
PND800-PND1600 |
최대 벌거벗은 와이어 직경: |
4mm |
보증: |
12 개월 |
China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine
This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.
Application:
This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.
Component:
Central pay-off. cage host,taping device (optional),capstan,take-up and traverse device,and electric control system.
Model | 400 | 500 | 630 | |
Inlet wire Dia.(mm) | Conductor | 1.5-3.5 | 1.8-4.0 | 2.0-5.0 |
Steel | 1.0-2.5 | 1.5-3.0 | 1.8-4.0 | |
Cores | 1.2-3.5 | 1.5-5.0 | ||
Frame rotation speed(r/min) | 700 | 600 | 400 | |
Stranding Pitch(mm) | 41-312 | 44-334 | ||
Linear Speed(m/min) | 27-205.3 | 22-166.85 | 14-108.9 | |
Capstan Dia.(mm) | 800+1000 | 1000+1200 | 1000+1250 | |
Size of tak-up bobbin | PN1250 | PN1600 | PN1600 |
FAQ
1.Q: Where is your factory located? A: Our factory is located in HEJIAN CITY, HEBEI PROVINCE, CHINA,
we are near Beijing, Tianjin and Shijiazhuang air port, and CANGZHOU WEST high-speed railway station.
2.Q: What is the advantage about your company? A: Our company has skilled technical engineer and workers and professional production line.
3.Q: Why should l choose your products? A: We are direct manufacturer, we can ensure the stable product quality and provide in time service.
4.Q: The logo and the color can be customized? A: Yes
5.Q:What's your near sea loading port: Tianjin port
